Cold Chain IoT Architecture Comparison — Proprietary vs. Open Standards for South African Operators

You’ve read about why the cold chain has an interoperability problem, explored where blockchain fits — and where it doesn’t, and now understand how EPCIS 2.0 creates a common language for supply chain events. Those articles addressed the why and the what. This one addresses the how.

Specifically: which monitoring architecture fits your operations?

South Africa’s cold chain doesn’t operate in a laboratory. It operates across load shedding schedules, cellular coverage gaps between Johannesburg and Durban, altitude effects at 1,700 metres on the Highveld, and cross-border corridors where connectivity disappears for hours at a stretch. The monitoring platform you choose needs to survive all of that — and still produce the data your business, your customers, and increasingly your export markets demand.

This guide maps the five main communication protocols and three platform architectures against South African infrastructure realities. It is not a product review. It is a decision framework — built on eight years and 770,000+ kilometres of refrigerated transport experience across Gauteng and Western Cape.

The Five Communication Protocols — and What They Mean for Your Operation

Every cold chain monitoring system depends on a communication protocol to move data from the sensor to a dashboard where you can act on it. The protocol you choose determines coverage, battery life, cost, and resilience during infrastructure disruptions.

Here is how the five main protocols compare:

Each of these has specific implications for South African operators. Let’s work through them.

Cellular (4G/LTE): The Workhorse Under Pressure

Cellular monitoring remains the default for fleet operations. A 4G modem on each vehicle transmits GPS coordinates, temperature readings, and door-open events to a cloud dashboard in near real-time. For urban and intercity routes — Johannesburg to Pretoria, Cape Town to Stellenbosch, N3 corridor to Durban — this works reliably.

The immediate risk is the legacy network sunset. MTN has confirmed plans to phase out 3G by the end of 2026. Vodacom has not locked in a specific date but is actively narrowing 2G spectrum. As of mid-2025, the South African government has shifted from imposing rigid shutdown deadlines to allowing operators to decide timing based on market readiness — but the direction is clear. If your fleet monitoring still runs on 2G or 3G modems, you are operating on borrowed time. Every new sensor deployment should be 4G/LTE minimum.

The gap is rural coverage. Between major centres — particularly on the N1 through the Free State, the N12 through the Northern Cape, and cross-border routes into Mozambique and Zimbabwe — cellular coverage thins or disappears entirely. For operators running those corridors, cellular alone is not sufficient.

NB-IoT: The Rising Option for Fixed Infrastructure

Narrowband IoT is purpose-built for low-power devices that transmit small packets of data infrequently — exactly the profile of a cold room temperature sensor. Vodacom has deployed NB-IoT across more than 8,000 sites nationally, covering an estimated 80% of the population. The technology operates on licensed LTE spectrum, which means quality of service is guaranteed and deep indoor penetration — roughly 20 dB better than traditional cellular — makes it ideal for sensors buried inside insulated cold rooms and warehouses.

MTN’s NB-IoT rollout remains in commercial testing phase. For now, Vodacom is the practical choice for NB-IoT deployments in South Africa.

The limitation is mobility. NB-IoT is designed for static or semi-static assets. It works excellently for a cold store in City Deep or a distribution centre in Epping, but it is not suitable for tracking a refrigerated truck moving at 120 km/h on the N1. For fleet monitoring, you still need cellular or satellite.

Battery life is the major advantage. NB-IoT sensors can operate for five to ten years on a single battery, depending on transmission frequency. That translates to genuinely deploy-and-forget infrastructure monitoring — a significant operational benefit for facilities with limited technical staff.

LoRaWAN: Powerful but Infrastructure-Dependent

LoRaWAN operates on unlicensed spectrum and offers impressive range — up to 15 kilometres in rural line-of-sight, 2–5 kilometres in urban environments. Sensor hardware is inexpensive, battery life extends beyond a decade in optimal conditions, and the protocol handles the intermittent, small-data transmissions that cold chain monitoring requires.

The catch for South African operators is that LoRaWAN requires you to deploy your own gateway infrastructure. Unlike NB-IoT, which rides on existing cellular towers, LoRaWAN needs gateways installed at your facilities, connected to power and internet backhaul. For a large cold storage campus or distribution centre with multiple buildings, this investment makes sense — you get a private monitoring network covering the entire facility at very low per-sensor cost.

For anything mobile — fleet tracking, route monitoring, last-mile delivery — LoRaWAN is not practical unless you are willing to build or subscribe to a regional gateway network. In South Africa, public LoRaWAN networks remain limited compared to markets like Europe or the United States.

The LoRa Alliance reports over 450 million LoRa-enabled devices deployed globally as of mid-2025, with the broader LoRaWAN IoT market projected to grow from approximately USD 7.7 billion in 2025 to USD 50 billion by 2035. The technology is proven at scale — the question is whether it fits your specific infrastructure footprint.

BLE/Bluetooth: Simple, Cheap, and Limited

Bluetooth Low Energy sensors are the most accessible entry point for cold chain monitoring. A BLE temperature logger costs a fraction of cellular alternatives, battery life is measured in years, and the technology is universally compatible with smartphones and tablets.

The operational model is straightforward: BLE sensors record temperature continuously. When a smartphone or dedicated gateway comes within range (typically 10–100 metres), it collects the data and uploads it to a cloud platform. Some systems automate this through fixed BLE gateways at loading docks or warehouse entry points.

For a small courier operation running 1–10 vehicles, BLE sensors paired with driver smartphones can provide compliant temperature records at minimal cost. The limitation is that you only get data when the sensor connects to a gateway — there is no continuous real-time visibility. If a driver’s phone dies or moves out of range, you have a data gap until the next connection.

For R638 compliance documentation — where you need to demonstrate temperature was maintained during transport — BLE with store-and-forward capability works. For real-time alerting during a temperature excursion on a two-hour delivery run, it does not.

Satellite: The Only Option When Cellular Fails

For cross-border operations running SADC corridors — Beit Bridge to Harare, Komatipoort to Maputo, or anywhere through the Northern Cape — satellite connectivity is the only way to maintain continuous monitoring where cellular coverage disappears.

Low Earth Orbit (LEO) satellite providers like Iridium (the only truly global IoT constellation, including polar coverage) and Globalstar offer IoT-specific data services designed for small, infrequent transmissions. Hardware costs have dropped significantly in recent years, with basic satellite IoT trackers available for considerably less than they cost five years ago. Subscription costs remain premium — typically R500–R1,000 per month per device for basic IoT data — but the alternative on remote routes is simply no data at all.

The satellite IoT market is projected to reach approximately USD 5.5 billion by 2030, and cost trajectories continue downward as LEO constellation capacity expands. For operators who need coverage everywhere, dual-mode devices that switch between cellular and satellite are increasingly practical.

When the Lights Go Out: Load Shedding and Protocol Resilience

South Africa’s load shedding reality — while reduced in recent months — remains a structural risk that every monitoring architecture must address. Here is how each protocol performs when the grid fails:

• Cellular towers typically carry four to eight hours of battery backup. During that window, your cellular sensors continue transmitting normally. Beyond that, you lose connectivity — but well-designed sensors with onboard data storage continue recording locally and transmit the backlog when connectivity returns. This “store-and-forward” capability is the single most important feature to verify with any monitoring provider.
• NB-IoT benefits from the same tower battery infrastructure as cellular, with an additional advantage: the extreme low power draw of NB-IoT sensors means the device itself can record data for months or years without external power. Even if the gateway or tower goes down temporarily, the sensor keeps logging.
• LoRaWAN gateways are the vulnerability point. Your sensors will continue recording data on battery power, but without a powered gateway, that data cannot reach your cloud platform. If you deploy LoRaWAN for facility monitoring, budget for UPS backup on every gateway. Without it, every load shedding event creates a monitoring blind spot.
• BLE is gateway-dependent. If the smartphone or BLE gateway loses power, data collection stops until reconnection. Sensors with onboard logging will preserve the data, but you will not see it until the gateway comes back online.
• Satellite is inherently independent of terrestrial power infrastructure — the constellation operates regardless of what happens on the ground. As long as the sensor device has battery power, it transmits. This makes satellite the most load-shedding-resilient option, though also the most expensive.
• The universal rule across all protocols: insist on store-and-forward capability. A sensor that only streams data in real-time and cannot log locally is a sensor that produces gaps in your compliance records every time connectivity drops — whether from load shedding, rural coverage holes, or border crossings. In South Africa, connectivity interruptions are not exceptions. They are operating conditions.

Platform Architecture: Proprietary, Open, or Hybrid?

The protocol gets data off the sensor. The platform is where that data lives, gets analysed, and produces the compliance records and operational insights your business needs. Here, you face a fundamental architectural choice.

The Proprietary Stack

A proprietary monitoring platform bundles everything — sensors, communication hardware, cloud platform, and dashboard — from a single vendor. You buy their sensors, data goes to their cloud, and you view it on their dashboard.

• The appeal is simplicity. One vendor, one support number, one invoice. The system works out of the box. For an operator who needs temperature monitoring running by next week, a proprietary turnkey system is the fastest path to compliance.
• The risk is lock-in. Your historical data sits in a vendor’s proprietary cloud. If you want to switch providers, you may lose that history. If you want to integrate monitoring data with your warehouse management system or transport management system, you are dependent on the vendor offering an integration — and many do not. If the vendor raises prices or discontinues a product line, your options are limited.

Several monitoring providers in the South African market offer complete proprietary packages. They work — but they create dependencies that become increasingly expensive to unwind as your operation scales.

The Open/Modular Stack

An open architecture uses standardised protocols and open data formats throughout. You select best-of-breed sensors from one manufacturer, connect them through a protocol-agnostic gateway, feed data to an open cloud platform, and build or customise your own dashboards and integrations.

• The appeal is flexibility and future-proofing. You own your data. You can switch any component without rebuilding the entire system. You can integrate monitoring data directly with ERP, WMS, and TMS systems. As EPCIS 2.0 adoption grows, an open architecture positions you to participate in interoperable supply chain data sharing.
• The reality check for most SA operators: a fully open stack requires significant technical capability to deploy and maintain. You need staff or consultants who understand IoT networking, API integration, and cloud platform management. For large logistics operations with IT departments, this is achievable. For a medium transport fleet, it may be more complexity than the business can support.

The Hybrid Approach — Most Pragmatic for SA Operators

For the majority of South African cold chain operations, the most practical path is a hybrid architecture: use a proprietary monitoring platform that offers open data access.

This means selecting a provider whose system works out of the box — with sensors, cloud, and dashboard bundled — but who also provides API access for integration, data export in standard formats (CSV, JSON), and a clear path toward EPCIS 2.0 compatibility.

Five questions to ask any monitoring provider before signing a contract:

1. Can I export my complete historical data in CSV or JSON format at any time?
2. Do you provide a documented API for integration with other business systems?
3. What happens to my data if I cancel my subscription?
4. Are you working toward EPCIS 2.0 compatibility for supply chain event data?
5. Can your sensors store data locally when connectivity is lost (store-and-forward)?

If a provider cannot answer yes to at least the first, third, and fifth questions, you are accepting a level of lock-in and data vulnerability that will cost your business as the industry moves toward interoperability.

Decision Framework: Matching Architecture to Operation Type

There is no single monitoring architecture that fits all South African cold chain operations. The right choice depends on fleet size, route profiles, infrastructure constraints, and where your business is headed. Here is a practical decision matrix.

Small Courier or Delivery Fleet (1–10 Vehicles)

• Recommended architecture: BLE sensors with smartphone gateway, or basic cellular (4G) tracker per vehicle.
• Priority: Simplicity and low cost. Your immediate need is consistent temperature records that demonstrate R638 compliance during deliveries. You do not need enterprise dashboards or multi-site integration yet.
• EPCIS readiness: Low priority at this stage. Focus on producing reliable, exportable temperature logs. If your provider offers CSV export, that is sufficient for now.
• Budget guidance: R2,000–R5,000 per vehicle for hardware setup, plus R150–R300 per month for connectivity and platform access.
• Load shedding mitigation: BLE sensors with onboard logging handle brief outages. Ensure driver smartphones stay charged — a vehicle USB charger is essential infrastructure.

Medium Transport Fleet (10–50 Vehicles, Mixed Routes)

• Recommended architecture: Cellular (4G/LTE) fleet monitoring with cloud-based platform. For any vehicles running routes with known coverage gaps, consider dual-mode cellular/satellite trackers.
• Priority: Real-time visibility across multiple vehicles and routes. Basic compliance reporting and temperature excursion alerts. The ability to demonstrate cold chain integrity to customers and auditors.
• EPCIS readiness: Medium priority. Ask potential providers whether they offer API access and are developing toward standardised data formats. Your next platform upgrade should move you closer to interoperability.
• Budget guidance: R5,000–R8,000 per vehicle for hardware, plus R300–R600 per month for connectivity and platform access.
• Load shedding mitigation: Cellular towers provide four-to-eight-hour backup. Verify that your chosen sensors have store-and-forward capability for outages that exceed tower battery life.

Large Logistics Operation (50+ Vehicles, Cold Stores, Multi-Site)

• Recommended architecture: Cellular (4G/LTE) for fleet monitoring, NB-IoT or LoRaWAN for fixed facility monitoring, integrated through a single cloud platform. This is where hybrid architecture — multiple protocols feeding one dashboard — becomes essential.
• Priority: Enterprise-wide visibility. Multi-site temperature monitoring with centralised alerting. Automated compliance reporting across fleet and facilities. Integration with WMS and TMS systems.
• EPCIS readiness: High priority. At this scale, interoperability between your monitoring system and your customers’ systems delivers measurable efficiency gains. Evaluate providers specifically on their EPCIS 2.0 roadmap and API maturity.
• Budget guidance: R50,000–R500,000+ for implementation depending on scope, plus R5,000–R50,000 per month for platform, connectivity, and support.
• Load shedding mitigation: UPS backup on all LoRaWAN gateways and critical network infrastructure. Generator backup for cold stores should already be in place. Monitoring system should alert independently of facility power — cloud-based alerting triggered by data absence is a useful secondary check.

Export-Focused Operation (PPECB, International Supply Chains)

• Recommended architecture: Cellular fleet monitoring with an EPCIS-compatible platform. If serving EU markets, blockchain-ready data capability becomes increasingly relevant as the EU Deforestation Regulation (EUDR) and Digital Product Passport requirements advance.
• Priority: Traceability and verifiable records. International standard compliance. The ability to share cold chain data with trading partners in formats they can consume and verify. PPECB export certification requirements already demand rigorous temperature documentation — EPCIS compatibility extends this into digital, interoperable territory.
• EPCIS readiness: Essential. EU market access will increasingly require standardised, machine-readable supply chain data. Investing in EPCIS compatibility now positions your operation ahead of regulatory requirements rather than scrambling to catch up.
• Budget guidance: Variable, but factor in EPCIS integration development, potential blockchain pilot participation, and platform capabilities beyond basic temperature logging.

Cross-Border Operator (SADC Corridors)

• Recommended architecture: Cellular (4G/LTE) as primary, with satellite backup for remote route segments. Dual-mode devices that switch automatically between cellular and satellite provide the best balance of cost and coverage.
• Priority: Continuous, unbroken monitoring across borders. Store-and-forward data logging is non-negotiable — you will traverse coverage gaps on virtually every cross-border route. Digital border verification readiness as SADC trade frameworks evolve.
• EPCIS readiness: High priority. Standardised, verifiable supply chain data will become a competitive advantage as digital trade documentation replaces paper-based processes at border posts.
• Budget guidance: R10,000–R15,000 per vehicle for dual-mode hardware, plus R500–R1,000 per month for combined cellular and satellite connectivity.

The Ten Questions — An Evaluation Checklist for Any Monitoring Provider

Before committing to any cold chain monitoring platform, ask these ten questions. The answers will tell you whether a provider is building for the interoperable future or locking you into a proprietary past.

1. What communication protocols does your hardware support? Look for 4G/LTE minimum. Bonus if they support NB-IoT or offer satellite backup options.
2. Does the sensor have onboard data storage (store-and-forward)? In South Africa, this is not optional. It is essential.
3. What is the battery life, and how does performance change during extended load shedding? Get specific numbers, not marketing claims.
4. Can I export my data in open formats — CSV, JSON, or via API? If the answer is no, walk away.
5. Are you working toward EPCIS 2.0 compatibility? Most providers will not be there yet. The important thing is whether they have it on their roadmap.
6. What happens to my historical data if I cancel the service? You should be able to export everything. If they hold your data hostage, that tells you everything about the relationship.
7. Can your platform integrate with WMS, TMS, or ERP systems? If you are a medium or large operation, this matters now. If you are small, it will matter soon.
8. What is the total cost of ownership over three years? Hardware plus subscription plus sensor replacement plus calibration. Get the complete number.
9. Do you use SANAS-calibrated sensors, or support third-party calibration? For pharmaceutical cold chain (GDP compliance) this is mandatory. For food transport, it demonstrates professional standards.
10. What is your roadmap for NB-IoT and 5G support? The answer reveals whether the provider is investing in their technology or maintaining legacy systems.

The Thread That Connects Everything

No single architecture fits all South African cold chain operations. A small courier fleet in Cape Town has fundamentally different requirements from a multi-site logistics provider running cross-border SADC routes. The protocols, platforms, and budgets differ accordingly.

But one principle applies regardless of operation size or type: prioritise data portability and open standards.

The monitoring platform you invest in today should be able to participate in tomorrow’s interoperable cold chain ecosystem. That means your data must be exportable, your platform must offer integration pathways, and your provider must be building toward — not away from — industry standards like EPCIS 2.0.

South Africa’s cold chain monitoring market is maturing rapidly. The global market is projected to grow from approximately USD 8.3 billion in 2025 to over USD 15 billion by 2030. Technology costs are falling. Protocol options are expanding. The operators who invest wisely now — choosing architectures that balance today’s operational needs with tomorrow’s interoperability requirements — will hold a structural advantage as the industry evolves.

The interoperability problem described at the beginning of this series is real. But so is the solution. It starts with the choices you make about the monitoring architecture underneath your operation.

For a comprehensive overview of all regulations, certifications, and compliance requirements affecting cold chain operators in South Africa, see our Compliance Matrix.
